Today at the Airport

The Experimental Aircraft Association  Chapter 1298 held a rally for Young Eagles.  The EAA Young Eagles program offers free airplane rides to children ages 7 through 17.   For many this is their first airplane ride, particularly in two to six seat General Aviation planes. In addition to the rides the kids receive a logbook signed by their pilot, and vouchers for an online private pilot course from Sporty’s Pilot Shop.

Dolly and I worked with other members who arrived early to be part of the ground crew. We are members of three EAA chapters, two in Florida and one in Michigan.

Waiting for the visitors at the Chapter Hangar
Lynn Postal and Piper Lance N146X
Paul Bryant and the Lightning he built
Don Whiting’s Piper Lance N222PP
James Chorvat’s retractable gear Cessna Cardinal 177












Paul Bryant built his Lightning ten years ago.  N82PB is registered as an AB or Amateur Built Aircraft.  The Lightning cruises around 150 miles per hour.

I have no photo of Tom Longo’s aircraft.  He made several flights today in N137JM his Vans RV9A, another Amateur Built Aircraft.

Five pilot members had their planes ready on the ramp and taxiways outside the EAA hangar.  The pilots donate their time, aircraft and fuel to give the youngsters their first small airplane ride.

Early morning pilot Briefing

An hour before the visitors arrive the pilots hold a briefing session where they agree on flight routes and review communications and other procedures necessary for safe operations.

Chapter 1298 Hangar

While they wait for their flight the visitors are invited to look around the EAA hangar and watch a video from EAA national.  The photo on the right shows the fuselage of a Vans RV10 that is being built by one of the chapter members.

Parents closely watching their children

Many parents bring cameras to Young Eagle events to record the children’s reactions following their flight.

The Ground Crew members register the children, escort them to the aircraft and introduce them to their pilot.  The pilots spend some time giving a preflight briefing and describing what to expect on the flight.

Pilots and Ground Crew

Downhill From Here?

On Friday November 11th N50KB had its first engine run.

A visit was scheduled with a FAA FSDO inspector for the afternoon of Wednesday the 22nd.  In the interim I completed wiring and testing the Pilot and PAX seat heaters; and sealed seven more firewall penetrations with red high temperature silicone caulk.

Wednesday morning I started the engine with the intention of taxiing to check the brakes.  It ran rough and was shut down.  The #4 cylinder was cold. Inspection showed valve movement was OK and another start was made.  The engine again ran rough for less than a minute and was shut down.  Instruments (Garmin G3X) showed the #4 CHT and EGT rose only to 150 and 205 degrees while the other cylinder temperatures appeared normal. An overly lean condition was suspected.  The #4 fuel injection restrictor was inspected and blown clean with air.

The FSDO inspector arrived and was told of the day’s activity.  I agreed to a suggestion we do an engine start.  During the start sequence the #4 EGT was seen to rise rapidly and then decline.  Other cylinder temperatures were normal.  The airworthiness inspection was terminated.  During post run discussion a fuel flow test and plug sparking test were suggested.

Fuel Flow Test

The fuel distribution test collected avgas from the four injector lines while the fuel boost pump was running.  This photo shows the results.

Fuel Flow Test Result

From left to right the cups contain the fuel for cylinders 1,2,3 and 4.  The overly lean condition of cylinder #4 is obvious.  There was likely a problem in the AVstat fuel distributor on the top of the engine.

Plug Sparking Test

The plugs were removed and their cases connected to engine ground by safety wire.  With the master and ignition switches on, the propeller was rotated by hand.  Sparks were observed from the plugs connected to the left E-MAG.  The plugs connected to the right E-MAG did not spark.

Brad at E-MAG Ignitions was contacted by phone.  He led us through several levels of tests that at end indicated the right E-MAG was operating OK.  He then asked me to remove the right E-MAG.  I was to verify the magneto shaft is engaging the drive gear in the engine accessory case.

I removed the E-MAG.  It’s shaft and gear look OK.  I then reached into the accessory case to feel the drive gear.  This is what my fingers found. A broken magneto drive gear in a factory new Lycoming YIO-360-M1B engine that ran a total of less than 1.1 hours, with over an hour of that time on the factory dynamometer.

Broken Section of Magneto Drive Gear

The following Monday began  a week of phone calls and emails with several levels of the Lycoming warranty organization.   Dolly had returned to Florida and before driving south I proceeded to pickle the engine with fogging oil and desiccator plugs for the winter.

Eventually Lycoming agreed to send a packing crate and pay to airfreight the engine back to the factory.  Dolly and I drove back to Michigan where I spent several days removing the engine from the plane and with help from friends preparing the shipment.  I took many photos of the process.  The engine arrived in Williamsport, PA on January 2nd.

Ready to Ship


September 1 – November 16, 2017

Could not yet see the light at the end of the RV7 build, but knew it was getting closer.  The list of accomplishments in the interim included:

  • Fastening the fuel tank “break away” tabs to the fuselage on each side.
  • Fabricating and installing the short fuel vent lines and connecting fuel supply lines between the wing and the fuselage

    Fuel Vent and Supply Lines
  • Making up brake lines with Berringer fittings to go from the firewall down to the wheel brakes.
  • Filling the brake calipers and lines up from the bleader valves to the reservoirs over the master cylinders
  • Final fastening the PAX baggage floor and PAX seat pan to underlying ribs with machine screws.  This and other tasks may sound simple, however I found them to take significant time.
  • Finished wiring the flap motor and position sensor

    Flap Drive Motor
  • Installing a quick drain valve on the left front oil sump drain.
  • Installing Clasic Aero aileron push-rod boots to seal out cold air.
  • Installing SCAT tubes from NACA air scoops to the instrument panel outlets
  • Timing of the PMags
  • Fitting the cylinder baffles and using the “Paper clip” method to trim the baffles 1/2″ from the cowl

    Paper Clips on the Engine Baffles
  • Fitting the oil cooler to the right rear engine baffle; doing the install and connecting oil lines

    Oil Cooler Mounted
  • Cuting and glassing the engine air intake snorkle between the air filter and the fuel servo

    Installed Wire Guide
  • Installing the ignition wire protectors that I designed last winter

    Left Wing inspection port
  • Closing up the six inspection ports in the wing bottom skins
  • Installing an alternate air door into the snorkle with control from the instrument panel
  • Installing all interior cover panels, baggage rear wall and pilot seat pan

    Blue RTV Engine to Baffle Seal
  • Sealing the engine to baffle gaps with Blue RTV
  • Installing wing to fuselage faring strips
  • Installing seat belts

Whew, and that’s not all.

Right Air Intake
Left Air Intake
Initial Cowl Trimming

The Vans upper and lower cowl halves had to be trimmed to fit each other and the fuselage firewall.  For October 30th we had a Halloween Lantern.

Our Halloween Lantern

The cowl interiors were painted with three coats of white two-part epoxy.

Upper Front Skin Inspection Port

I copied the practice of many Vans builders and cut an inspection port into the upper skin in front of the canopy.  This provides access to the break fluid reservoirs, the voltage regulators and the forward sockets of the VPX power box.

Installing the Top Front Skin

Another deviation from the Vans standard is that I fabricated and installed a plenum cover over the top of the engine, rather than the usual flexible baffle strips that seal the baffles to the top cowl.

Fiberglass Engine Plenum

The potential advantages of a plenum in cooling efficiency and reduced wear on the cowl have been often debated on the Vans Airforce website forums.  Casting of the plenum was discussed in an earlier post.

Checking Plenum Clearance to Cowl

Clay risers were set on the plenum to verify 1/2″ clearance from the cowl.

Fitting the Plenum to the Engine Baffles

Aluminum and fiberglass edges were set with platenuts for fastening to the engine baffles.

  • Catto Propeller

    The Catto three blade wood/carbon fiberglass propeller was installed.  Specifications:

  • 68″ diameter
  • 74″ Pitch
  • Nickle leading edges
  • Design RPM 2750
  • Red Line RPM 3300

Prior to first engine start start the fuel tanks were calibrated and a weight and balance prepared.  Both of these steps will be repeated as the W&B indicates a heavier spinner ‘crush plate’ will be needed to move the center of gravity further forward.

Lycoming Service Bulletin No.632

While we were in Oshkosh, WI for the annual EAA convention, Lycoming announced a manditory service bulletin for about 1300 engines that had been manufactured in 2016, plus all engines that had been overhauled with new piston rods around that time.  Our engine serial number was one of those listed.  The inspection involved purchasing and using a special tool to find those connecting rods that may have looser than specified bearings in their upper ends.

An FAA Airworthiness Inspector friend who once owned an aircraft engine overhaul shop helped me get the job done.

Lycoming S/B 632 Inspection

The photo shows the tool (a big coil spring attached to the #4 cylinder’s rod.  If the bearing starts to slide out when the spring is compressed by six turns of its inner bolt, it fails.  We were lucky all four rods passed.  Note the red cylinder base o-rings that are used to keep the connecting rods from flopping around during the disassembly. The S/B was just a PITA that slowed progress by three days.

August 10 to August 29, 2017

The Garmin G3X Touch Configuration Menu starts here

Soon after the wings were mounted the FAA approved a Registration Certificate for Vans RV7 N50KB, known to us as “The Dream Weaver”.   That didn’t reduce the number of tasks yet to be accomplished.  I next

  • installed gussets connecting the fuselage side skins to the wing main spar. Two of the 1/4″ bolts were too short and were replaced by Vans.
  • Installed the 22 #8 screws that attach the lower wing skins to the fuselage bottom skin
  • Bolted the wing rear spars to the center rear spars.  This required removing and reinstalling the flaps.  Flap push-rod lengths were adjusted to synchronize the two flaps.
  • Connected aileron push-rods to the center section controls
  • Installed the outside air temperature probe onto a right wing inspection plate
  • Confirmed the angle between the wing top skin and the flap top skins are 45 degrees when in the down position
  • Identified, tested, labeled and prepared the 28 wing light wires for connection to a terminal strip under the PAX seat.  The LED landing lights draw 13.3 amps and were assigned a 15 amp breaker in the VPX Pro electronic breaker box.
  • Worked through the Garmin menu structure to find the VPX control page on the MFD screen.
  • Then connected the VPX box’s serial port to my laptop computer and configured the breaker ratings for each circuit.

    A VPX Pro Configuration Screen on a Laptop Computer
  • Set the graphical image colors and limits for the Garmin screen’s graphical flap, fuel, and trim position indicators.
  • Threaded the pitot and AOA tubes up from the left wing root through the armrest support and on to the instrument sub panel where they were connected to the #1 and #2 ADAHRS units.
  • Filmed the ease of flight control movement.
  • Installed fuel lines between the wing tanks and the fuselage manifold.

Then it became time to do the inspection required by the newly announced Lycoming Service Bulletin #632.

The Flightless Bird Grows Wings

Waiting for Wings

For over a year, the wings have sat in their cradle waiting for this day.  Working on the fuselage was easier without the wings attached.  The day came when the next step in wiring was to connect the wing mounted taxi, landing, navigation and recognition lights.

I asked several RV friends to help Dolly and I with the job.

Getting Ready

Word spread around the airport and a gaggle of help arrived.  Knowing I would be in the cockpit driving close fitting bolts connecting the wings to the center section, I told everyone that Dolly was the floor manager for the operation.  She had helped when we did the test fit of the wings a year earlier.

Before mounting the wings, we sorted out the coils of lighting wires and fed them into the fuselage.  We started with the left wing.  Both wings had been laid out on padded sawhorses next to the plane.  This was for safety in case we had to halt the process mid-way to completion.

In 2016 the wings were test fit and retained with lubricated drift pins that I had made from hardware store bolts in a mini-lathe.  Now for each wing, two drift pins were driven in bolt holes before driving the first close tolerance bolt.  The pins provide initial alignment and are then replaced by bolts.

There are a total of eight 7/16″ and eight 1/4″ close tolerance bolts holding the wings to the fuselage center section main spar.  They give one confidence in this aerobatic airplane.


When the wings were on we all enjoyed a great lunch of Subway sandwiches and cool drinks that Dolly had laid out.

All in all, it was a great day!



Back to Building

May 2017 to August 8, 2017

November 2016

When we left toward Florida in the fall of ’16 the engine had just been mounted.  The weather was getting cold.  I was OK with the heated hangar but I would be batching it if I didn’t follow Dolly South.  Besides, all I had to do was hookup a few hoses and wires.

Hah!! Little did I know.

May 2017

May was all firewall forward work.  It included:

  • Installing the oil filler neck
  • Installing NGK BR8ES 3961 spark plugs gapped to 0.31”
  • Installing the exhaust pipes lubed with Mouse Milk
  • Installing the cabin heat muff on the #1 cylinder exhaust pipe
  • Installing vibration dampers on the exhaust stacks
  • Mounting the throttle servo body to the engine
  • Fabricating mounts and installing the throttle, mixture and other controls required drilling the firewall and making up cable fittings and linkages to the engine
  • Installing fuel lines from the engine pump to the fuel servo, and on to the fuel divider
  • Installing an overflow line from the engine fuel pump
  • Installing a multi-pressure manifold on the firewall
  • Drilling exhaust stacks and installing four Exhaust Gas Temperature sensors
  • Installing fire sleeve in several places
  • Installing four Cylinder Head Temperature sensors
  • Installing a Red Cube fuel flow sensor in the fuel servo to fuel divider line
  • Installing SCAT tubing from the heat muff to the firewall heater box

    Heater Muff, SCAT tubing, and fuel servo with Red Cube fuel flow sensor under fire sleeve
Pressure Manifold on upper left firewall







  • Installing fuel, oil and manifold pressure lines and sensors
  • Installing a voltage regulator for the backup alternator
  • Forming and installing the crankcase breather tube with “whistle slot”
  • Threading and lacing the wire bundle going to the Garmin GE24 engine sensor box
  • Routing the lower spark plug leads from PMags to cylinders.

    Lower ignition wires installed

May was a busy month of 5-8 hour days in the hangar.

June 2017

I took June 1st off to do EAA Chapter 77 treasury work.  After that the month included:

  • Mounting the primary alternator and wiring the field and ground lines back through the firewall

    ANL Fuses and shunts
  • Fabricating buss bars, mounting ANL fuse blocks on the lower right firewall and connecting shunts to the Garmin GE24 amperage sensor inputs.
  • Installing an alternator fail light for the main alternator.
  • Cutting and fitting nine high amperage cables for the alternators, battery and starter.
  • Installing IN5407 diode spark suppression jumpers for the Master and Starter solenoid coils.
  • Installing a starter “kill switch” hidden below the instrument panel
  • Drilling a 1″ dia. hole in the rear wing spar IAW Van’s instructions to pass the magnetometer plug
  • Lacing spark plug wires with wire ties to keep the wires separated
  • Testing electrical system components including a starter switch green light and annunciator panel
    Green Starter Switch Light turns off when engine runs.

    Shelf for Terminal Block
  • Fabricating a small shelf for Mounting a terminal strip under the PAX seat.  The lighting control switches were the first connections to these terminals.

    Terminal Block under PAX seat




  • Running various wires from the instrument panel to junction strips below the  Pilot and PAX seats.  The pitch and roll servo cables traverse the right side vertical channel.  The Magnetometer cable is in the left side channel.  All wires were eventually bundled in corrugated flex tubes; some covered with “snake skin”.
    Left Wiring Channel

    Right Wiring Channel







Pilot Headset Socket


  • Fabricating Pilot and PAX headset socket brackets and mounting them on the sides below the instrument sub-panel.
  • Installing the Emergency Locator Transmitter  on the tunnel cover in front of the seats.  The ELT antenna was mounted on a shelf behind the PAX seat.  Lithium batteries having a 10 year life were installed in the ELT and the panel mounted alarm.  They should be replaced before July 2027.

July 2017

The daily work continued and I

  • Removed the front crankshaft expansion plug and pierced the rear plug.  Then, I installed a new front plug per Lycoming Service Bulletin No. 1435, converting the engine to fixed pitch operation.
  • Fabricated a firewall shelf for mounting the Garmin GPS antenna under the fiberglass cowl.

    GPS Antenna shelf
  • Installed the Comm Radio antenna under the plane and on the fuselage center line
  • Installed a blade antenna under the pilot seat for the Garmin GDL-39R ADSB receiver
  • Installed another blade antenna under the PAX seat for GTX23ES transponder.  RG400 coax cable was used for all antennae.

    Flywheel and crankshaft extension
  • Mounted the flywheel and a 2-1/4″ Saber Engineering crankshaft extension to the engine, torquing the combination to 50 ft-lbs with Locktite 248
  • Installed the Comm Radio, GPS Nav, PFD & MFD EFIS, and TPX in the aircraft and began testing

    Initial fitting of engine baffles
  • Fit the front, side and back baffles to the engine.
  • Dolly and I attended the week long Oshkosh EAA Airventure 2017.  There we learned of Lycoming Service Bulletin No. 632.  Our engine serial number was included in the list of ~1300 that left the factory with potentially insecure connecting rod upper bearings.

August 1 through 8, 2017

Arriving back in Michigan I ordered the tool required to do the S/B #632 inspection. It was back-ordered.  Continuing with the build, I

  • Calibrated ADHRS #1 and #2 pitch & roll servo offsets and ran many Garmin G3X post-install tests.  The left screen in the photo shows when I stumbled onto the Garmin G3X Touch Engineering Test Screen that is not normally available to the customer.

    Garmin instrument panel – testing
  • Installed pitot/AOA tubes and wires.

Then came the day we had long awaited – the plane was ready to receive its wings!
